R3100C

Lepton3

Lettore RAIN RFID 25dBm 1-Port

img R3100C

BENEFITS

  • Ultra compact size
  • High sensitivity
  • Surface mount device (SMD)
  • Serial interface
Caratteristiche
  • RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
  • Multiregional support
  • Ultra compact size
  • Up to 25 dBm (316mW) output power
  • Serial interface (TTL Levels)
  • Low power consumption
Applicazioni
  • Handheld devices
  • Multiregional label printers and applicators
  • Points of sale readers
  • Voice operated gloves
  • Smart appliances for home automation
  • Security and access management systems
Panoramica

Il Lepton3 (Modello R3100C) è un lettore embedded ultra compatto della linea di prodotti easy2read©, adatto ad applicazioni RAIN RFID che richiedono bassa potenza e prestazioni di medio livello.
Con una potenza programmabile da 10 dBm a 25 dBm, il lettore può rilevare tag da 3 metri di distanza (a seconda delle dimensioni del tag o dell’antenna).
Grazie al basso consumo di energia, il modulo è progettato per essere facilmente integrato in dispositvi alimentati con batteria.
Il cuore del modulo, costituito dal chip Impinj E310 permette di ottenere elevata velocità di lettura e di ottenere prestazioni al top della sua classe in ambienti ad alta densità di tag e lettori.
La compattezza del dispositivo, unita alla tecnologia a montaggio superficiale, permette al Lepton3 di essere inserito all’interno di palmari industriali, accessori per smartphone e altri dispositivi di piccole dimensioni.
Il Lepton3 è conforme alle normative europee e statunitensi, ed è quindi ideale per l’integrazione in dispositivi che richiedono la conformità a diverse regioni geografiche.
Il Lepton3 è pin-to-pin e software compatibile con i moduli Impinj RS1000 ed RS500, proponendosi come perfetto sostituto di questi dispositivi.

Frequency Range

865.600÷867.600 MHz (ETSI EN 302 208 v. 3.3.1)
902÷928 MHz (FCC part 15.247)

RF Power

Configurable from 10dBm to 25dBm (from 10mW to 316mW) conducted power

RX Sensitivity

-72dBm – 10%PER, assuming 20dB antenna RL @ 25dBm output

Antenna VSWR Requirement

< 2:1 for optimal performance

Antenna Connectors

50 Ohm mono-static RF port on a single pin

Frequency Tolerance

± 10 ppm over the entire temperature range

Number of Channels

4 channels (compliant to ETSI EN 302 208 v. 3.3.1)
50 hopping channels (compliant to FCC part 15.247)

Standard Compliance

EPC Class 1 Gen 2 – ISO18000-63

Connectivity

UART Serial Port:

  • Baudrate: from 9.6 to 921.6 kbps, default 921.6 kbps
  • Databits: 8
  • Stopbit: 1
  • Parity: none
  • Flow control: none

3.3 V I/O voltage level

I/O Interface

4 I/O lines 3.3 V level
Iout @ 8 mA max.

Power Supply

3.2 ÷ 5.25 V DC

Power Consumption

– 800 mA @ RF out = 25 dBm
– 5 mA in idle mode – Ready to receive commands

Dimensions

(L) 32 x (W) 29 x (H) 4.1 mm3
1.26 x 1.14 x 0.16 inches3

Package Type

32 pin surface mount module (SMT compatible)

Operating Temperature

-20°C to +70°C

Weight

5.4 g

Name
Revision
R3100C Lepton3 Firmware
1.1.0

Name
Revision
R3100C Lepton3 Technical Information Manual
1
Easy Controller Software Technical Information Manual
5
R3100C Lepton3 Moisture Sensitive Level 3 (MSL 3)
1
CAEN RFID SDK Technical Information Manual
1
easy2read Protocol Technical Information Manual
19

Name
Environment
OS-Version
Revision
Easy Controller Software Windows version
.Net
11/10
1.13.0
R3100C Lepton3 Upgrade Tool
10/7
1.4.0
CAEN RFID SDK
.Net Standard,Android,C,C++,Java,Swift
10/7/8/Vista/x64bit 7/x64bit Vista/x64bit XP/XP
5.0.0

Name

R3100C Lepton3 Data Sheet

REACH Declaration of Conformity
R3100C Lepton3 CE Declaration of Conformity
R3100C Lepton3 FCC Grant part B
R3100C Lepton3 FCC Grant part C
R3100C Lepton3 UKCA Declaration of Conformity

R3100C Lepton3 - R7100C Lepton7 Technical Drawings

CAEN RFID Products Catalog

WR3100CXAAAA
R3100C - Lepton3 - 25dBm 1-Port RAIN RFID Reader Module
WRHML37XDKEU
R1271C, R3100C, R7100C and R9100C - ETSI Dev Kit with antenna, interface, power supply and tags (reader not included)
WRHML37XDKUS
R1271C, R3100C, R7100C and R9100C - FCC Dev Kit with antenna, interface, power supply and tags (reader not included)
WRHML37XEVBX
Evaluation Board for R1271C, R3100C, R7100C and R9100C
